Engineering a Reliable R Package for Regulatory Use Using “rpact” as an Example

useR! 2024, Salzburg, Austria

Friedrich Pahlke and Gernot Wassmer

RPACT

July 10, 2024

Motivation: Why validate an R package?

Why validate an R package?

In many industries, it is necessary to ensure that the software does what it is supposed to do, e.g.:

• Finance: Trading systems, payment platforms, risk management
• Automotive: Autonomous driving, engine control, safety systems
• Manufacturing: Automation, production monitoring, quality control
• Pharmaceuticals and Medical Devices: FDA/EMA regulations, trial design and analysis, diagnostic software

… R is used in more and more industries.

Why validate an R package?

Validation guidelines in various industries:

• GxP¹: “Good Practice” guidelines

Examples:

• GMP: Good Manufacturing Practice
• GLP: Good Laboratory Practice
• GCP: Good Clinical Practice

1. The “x” is a placeholder for specific areas

Why validate an R package?

Example today:

• Regulatory use in pharmaceutical¹ industry
• Software validation is essential for the approval of new drugs and treatments
• Major risk of faulty software: Incorrect decisions about the safety and efficacy of drugs or treatments

1. The concept can also be transferred to other industries

The “rpact” Example: Engineering a Reliable R Package for Regulatory Use

• 2017: Idea

  …

• 2024: “rpact” and RPACT are trusted and widely accepted

What does GxP-compliant validation mean for R packages?

• Show that the R package is “reliable”¹
• This can be demonstrated through traditional formal validation, as shown later with “rpact”
• Or through a less formal “Risk Assessment” approach, as promoted by the R Validation Hub (pharmar.org/risk)

1. For example, the FDA has stated that the R packages used must be “reliable”

Status 2024: RPACT in Numbers

• 1,500,000 € sponsorship money
• 62,000 CRAN downloads total; 1,600¹ downloads per month (June 2024)

• 36,593 lines of code
• 34,427 unit tests covering 29,701 lines of code (see codecov.io)
• 20,000 hours of work
• 98 separate source code files: Modular software design
• 29 vignettes based on Quarto and published on rpact.org/vignettes
• 28 releases on CRAN since 2018

1. In a server-based environment, 1 download can represent up to 500 potential users

• 20 SLA sponsors: “The RPACT User Group”
• 8 websites: CRAN, rpact.com, rpact.org, GitHub, GitHub Pages, OpenSci R-unisverse, METACRAN, Codecov
• 4 CI/CD pipelines on GitHub to automate checks, tests, code coverage calculation, and GitHub pages creation
• 3 imported dependencies: knitr, Rcpp, and R6
• 3 suggested dependencies: ggplot2, testthat, and rmarkdown
• 2 main developers; 3 contributors; feedback and feature requests from many different users and companies
• 2 rpact Shiny apps: rpact Shiny app and RPACT Cloud
• 1 developer platform: GitHub is used for issues, comments, feature requests

Project Challenges 2017

Challenge 1: Funding

• Crowdfunding
  \(\rightarrow\) 10 pharma companies and CROs agreed to sponsor the project
• Service Level Agreement
  \(\rightarrow\) Together we developed a simple contract: software support and training; no software development!
• RPACT was founded as a GbR \(\rightarrow\) Easiest and fastest solution for freelancers

Current “RPACT User Group”: Boehringer Ingelheim, Metronomia Clinical Research, F. Hoffmann-La Roche, Dr. Willmar Schwabe, Bayer, Merck, AbbVie, Dr. Falk Pharma, Klifo, FGK Clinical Research, UCB, GKM, Parexel, Nestlé, Janssen (Johnson & Johnson), Novartis, PPD (Thermo Fisher Scientific), Sanofi, Pfizer, Gilead

Challenge 2: Realization with a small team

• Collaboration, project management, version control, bug tracking, feature requests
  \(\rightarrow\) GitHub
• Integrated development environment (IDE)
  \(\rightarrow\) Eclipse + StatET, RStudio IDE
• Clean code rules for R packages
  \(\rightarrow\) We developed own guidelines inspired by Java and widely accepted clean code rules (see Robert C. Martin (2009) Clean Code)
• Test, validation, and release
  \(\rightarrow\) Automation wherever possible

Challenge 3: Sustainable user concept

• Usability (easy to learn and use; high user acceptance):
  • Many default arguments \(\rightarrow\) Getting started is much easier
  • Support of R generics \(\rightarrow\) print(), plot(), summary(), names(), …
  • Inline help and documentation \(\rightarrow\) roxygen2
  • Vignettes \(\rightarrow\) Practical examples and tutorials

• Consistency:
  • Lower camel case names
  • Clear output format: structured and meaningful

Challenge 4: Validation Concept

• Formal validation inspired by
  “GAMP¹ 5” principles
• As few dependencies as possible because we cannot validate other R packages
• We assume that base/core R is validated/reliable (see R-FDA.pdf)
• High test coverage²:
  Usage of covr and codecov.io

1. ISPE GAMP® 5: A Risk-Based Approach to Compliant GxP Computerized Systems

2. A high test coverage (\(\geq\) 80%) ensures that code changes do not have unwanted side effects

• Comprehensive validation documentation
• Automation of recurring validation processes/activities
  • Utility package rpact.validator
  • CI/CD pipeline on GitHub to automate checks, tests, code coverage calculation, and GitHub pages creation
• Template-based unit tests: Automatic generation of
  • testthat test cases
  • test plans and references to functional specifications
  • test protocols directly linking to individual test cases

Basic Idea of Template-Based Unit Testing

• Step 1: Compare software results manually, e.g., with simulation results and results from the literature and/or other programs
  \(\rightarrow\) Reference point is correct and trustworthy
• Step 2: Fix the validated state, i.e., generate unit tests which test the software systematically and reproducibly
  \(\rightarrow\) Further development and refactoring do not cause undetected side effects

Advantages of the Template-Based Approach

1. Automation and Consistency:
   • Uniform Test Structure: Improving maintainability and readability
   • Automated Test Generation: Reduces manual effort and minimizes errors
2. Flexibility and Extensibility:
   • Easy Switch of Test Packages: Replace testthat by another test framework
   • Extensibility: Add new tests for all functions and results in one code location

3. Traceability and Documentation:
   • Granular and Traceable Tests: Each test case is clearly defined and traceable, making debugging easier.
   • Documentation: References to functional specifications and software design specifications can be defined in the templates
4. Efficiency Improvement:
   • Time Savings: Test templates can be reused to generate tests automatically
   • Scalability: Tests can easily be scaled to new functions and modules, increasing test coverage

Conclusion

• Validation of an R package is challenging, time consuming, and expensive
• Applying good software engineering rules is essential to achieve high user acceptance, especially in a GxP regulated environment
• The template-based unit testing approach offers a structured, flexible, and efficient method for software quality assurance
• The combination of manual validation and automated verification ensures that the software remains stable and reliable, even as it is further developed or refactored
• In small teams, a high level of automation right from the start makes life much easier

Further Information

• Example of a template-based unit test definition:
  rpact-com.github.io/user2024-presentation
• Visit our website: rpact.com
• Ask a question or connect: Friedrich Pahlke

Thank you!
